Target Drone LX-WR-50

Product Overview

The Target Drone LX-WR-50 is a multi-purpose UAV with capabilities for both high-altitude and ultra-low-altitude flight.

Environmental Adaptability: Designed to operate in extreme environments including temperatures from -40°C to +65°C storage, -20°C to +50°C startup, high humidity, light rain, and high altitude up to 4600m plateau regions.

Mission Flexibility: Supports day/night flight and multi-UAV formation missions. Features typical skin/stringer/frame composite structure with engines mounted on both sides of the rear fuselage for stability and durability.

Control Modes: Dual core control modes – remote control and programmed control, plus safe autonomous recovery mode (except ultra-low altitude). Exceptional mission adaptability and safety.

Core Features

✓
Extreme Environment
-40°C to +65°C storage, high altitude 4600m
✓
Day/Night Flight
24-hour operational capability
✓
Formation Flight
18-UAV formation, ≤5s sync error
✓
High Reliability
MTBF ≥100 hours, ≥40 flight cycles
✓
Dual Control Mode
Remote/Programmed control + safe recovery
✓
Dual-Band Comm
Dual-frequency + hot backup

Specifications

FUSELAGE LENGTH
4.0m (excluding pitot tube & tail cone)
WINGSPAN
1.79m
BODY HEIGHT
0.705m
MAX TAKEOFF WEIGHT
≤260kg
MAX PAYLOAD
≤55kg (tracer/IR decoys or combo)
MAX SPEED
≥1080km/h (300m/s)
MIN SPEED
≤396km/h (110m/s)
SERVICE CEILING
≥12000m (relative altitude)
MIN FLIGHT ALTITUDE
≥98m (land & sea, ultra-low altitude)
ENDURANCE
≥70min
CONTROL RADIUS
≥300km
WIND RESISTANCE
Max takeoff wind ≥10m/s (~Level 5)
WEATHER ADAPTABILITY
Light rain flight capable
STORAGE TEMP
-40°C ~ +65°C
STARTUP TEMP
-20°C ~ +50°C
HUMIDITY
≥(95±3)% (at ≥35°C)
AIRCRAFT LIFE
≥40 cycles (drop test)
GROUND EQUIPMENT MTBF
≥100 hours
ROUTE CONTROL ACCURACY
Alt. error ≤10m, Track error ≤50m
FORMATION CAPABILITY
18-UAV formation, sync error ≤5s
CONTROL MODE
Remote/Programmed + Safe Recovery
LAUNCH
Rocket ignition, one-click start at 4600m
RECOVERY
Autonomous fixed-point/directional/emergency
SPECIAL CAPABILITIES
Day/Night flight, High altitude takeoff
